We are engaged in offering a comprehensive range of Oil Chillers, which is manufactured using quality material, sourced from authenticated vendors.
These oil chillers are further used in cutting, lubrication, broaching, honing, quenching, drilling, & grinding. As we know the oil needs to be maintained at a certain temperature range, and to intact its physical and chemical properties the oil chillers are required.
TECHNICAL DATA FOR YUKTA GROUP OIL CHILLERS :
| Capacity in TR | 0.5 TR to 5 TR |
|---|---|
| Operating Voltage | 415v |
| Refrigerant | R-134a, R-22 |
| Compressor | Scroll /Sealed / Semi-sealed compressor |
| Pump LMP (Flow in LMP) | 10/80 |
FEATURES OF OIL CHILLERS :
- Additional interlocks apart from high temperature alarm
- Micro processor based chiller controller
- CFC free, environmental friendly refrigeration system
- Specific designs to meet customer requirements for low temperatures also available
- In case of low pressure, L.P / H.P. switches turn off
- Temperature indicator
- Flow meter/ Low flow switch
- Safety fuse for mains & compressor
- Built-in overload protection for compressor
- Single phase preventer for cooling system
APPLICATIONS :
- Deep hole drilling machines
- Pipe bending machines
- Hydraulic power packs
- Special purpose machines
- Injection molding machines
- Die casting machines
- Hydraulic presses
- Spindle head cooling
- Component quenching
- Broaching machines
